illbruck sealing film

The TwinAktiv window foil EW, made from spunbonded fabric with a moisture-variable membrane, has anSd value of between 0.3 and 20 m, and offers reliable protection against moisture entering the window joints.

Due to the variable Sd value , the sealing foil also fulfils theRAL -requirement of being internally more vapour tight than outside.

The vapourproof film for windows is self-adhesive on both sides (12 N/25 mm adhesive strength) and can therefore be used as both double-sided and single-sided. Simply remove the protective film on the respective side, markings indicate which of the two sides can be plastered over (printed side). The sealing film can be used in a variety of different ways which facilitates planning certainty when installing windows, as it is easy to distinguish the adhesive sides, and the sides which can or cannot be plastered over.

Indestructible window sealing film

The film is also suitable for waterproofing buildings due to its excellent resistance properties:

• Temperature resistance from -40 to +80 °C
• Compatible with conventional building materials according to DIN 52452
• Sealing foil impervious to driving rain up to 600 Pa
• Maximum tensile strength of 95/5 cm (transverse) and 180 N/5 cm (longitudinal)
• Tear growth resistance of 65 N (transverse) and 60 N (longitudinal)
• UV resistance approx. 3 months

The sealing film keeps windows and joints dry over the long term, even in particularly unfavourable weather conditions such as heavy rain or hail. According to DIN 4102 it is classed as a normally flammable component (Class B2 ).

The self-adhesive sealing film for window installation

To protect the connecting window joints from moisture, it is essential to use a sealing film when installing a new window. Self-adhesive sealing foils such as the TwinAktiv EW window foil have the advantage that they stick to the window frame without additional adhesive. They must be attached to the masonry with adhesive, butyl or a plaster grid. Using this type of sealing foil saves time, and avoids errors during installation. In addition to the practical foil, windows24.com also offers you a wide selection of tools and accessories for window and door installation.
